Product information sheet
|
Supplier’s name or trade mark: CHANGZHOU
TOPKING INTERNATIONAL TRADE CO., LTD |
||||
|
Supplier’s address : room 409.no.1 fuchen
building.no.8 taihu east road,changzhou.jiangsu.china |
||||
|
Model identifier: RS-TLA015 |
||||
|
Type of light source: LED |
||||
|
Lighting technology
used: |
LED |
Non-directional or
directional: |
NDLS |
|
|
Mains or
non-mains: |
MLS |
Connected light
source (CLS): |
NO |
|
|
Colour-tuneable light
source: |
NO |
Envelope: |
NO |
|
|
High luminance
light source: |
NO |
|
|
|
|
Anti-glare shield: |
NO |
Dimmable: |
NO |
|
|
Product parameters |
||||
|
Parameter |
15W |
Parameter |
6500K |
|
|
General product
parameters: |
||||
|
Energy consumption
in on-mode (kWh/1 000 h) |
15W |
Energy efficiency
class |
G |
|
|
Lamp Base |
E27 |
Bean Angle |
220° |
|
|
Useful luminous
flux (Φuse),
indicating if it refers to the
flux in a sphere (360°),
in a wide cone (120°) or in a narrow cone (90°) |
1200LM |
Correlated colour
temperature, rounded to the nearest
100 K, or the range of correlated colour temperatures, rounded to the
nearest 100 K, that can
be set |
6500K |
|
|
On-mode power (Pon),
expressed in W |
15W |
Standby power (Psb), expressed in W
and rounded to the second
decimal |
NO |
|
|
Networked standby power (Pnet) for CLS, expressed in W and rounded to
the second decimal |
NO |
Colour rendering index, rounded to the nearest
integer, or the range of CRI-values that can be set |
80 |
|
|
Outer dimensions
without separate control gear, lighting control parts and non-lighting
control parts, if any (millimetre) |
Height |
126 |
Spectral power
distribution in the range 250 nm to 800 nm, at full-load |
|
|
Width |
70 |
|||
|
Depth |
70 |
|||
|
Claim of equivalent power (3) |
N/A |
If yes,
equivalent power (W) |
|
|
|
|
|
Chromaticity coordinates (x and
y) |
X=0.3110
Y=0..3330 |
|
|
Parameters for
directional light sources: |
||||
|
Peak luminous
intensity (cd) |
N/A |
Beam angle
in degrees, or the range of beam angles that
can be set |
N/A |
|
|
Parameters for
LED and OLED light sources: |
||||
|
R9 colour rendering index value |
20 |
Survival factor |
0,7 |
|
|
the lumen maintenance factor |
0.7 |
|
|
|
|
Parameters for
LED and OLED mains light sources: |
||||
|
displacement factor (cos
φ1) |
0.5 |
Colour consistency
in McAdam ellipses |
6 |
|
|
Claims that
an LED light source replaces a fluorescent light source without integrated ballast of a particular wattage. |
NO |
If yes
then replacement claim (W) |
- |
|
|
Flicker metric
(Pst LM) |
0.2 |
Stroboscopic effect
metric (SVM) |
0.2 |
|
