Supplier’s name or trade mark: CHANGZHOU TOPKING INTERNATIONAL TRADE CO., LTD
|
|
Supplier’s address (1) :room 409.no.1 fuchen building.no.8 taihu east road,changzhou.jiangsu.china
|
|
Model identifier: RS-BJ004
|
|
Type of light source:LED
|
|
Lighting technology used:
|
LED
|
Non-directional or directional:
|
NDLS
|
|
Light source cap-type(or other electric interface)
|
E14
|
|
|
|
Mains or non-mains:
|
MLS
|
Connected light source (CLS):
|
NO
|
|
Colour-tuneable light source:
|
YES
|
Envelope:
|
NO
|
|
High luminance light source:
|
YES
|
|
|
|
Anti-glare shield:
|
YES
|
Dimmable:
|
NO
|
|
Product parameters
|
|
Parameter
|
4W
|
Parameter
|
3000K
|
|
General product parameters:
|
|
Energy consumption in on-mode (kWh/1 000 h)
|
4
|
Energy efficiency class
|
E
|
|
Useful luminous flux (Φuse), indicating if it refers to the flux in a sphere (360°), in a wide cone (120°) or in a narrow cone (90°)
|
470Lm
|
Correlated colour temperature, rounded to the nearest 100 K, or the range of correlated colour temperatures, rounded to the nearest 100 K, that can be set
|
3000k
|
|
On-mode power (Pon), expressed in W
|
4W
|
Standby power (Psb), expressed in W and rounded to the second decimal
|
NO
|
|
Networked standby power (Pnet) for CLS, expressed in W and rounded to the second decimal
|
N/A
|
Colour rendering index, rounded to the nearest integer, or the range of CRI-values that can be set
|
80
|
|
Outer dimensions without separate control gear, lighting control parts and non-lighting control parts, if any (millimetre)
|
Height
|
97mm/117mm
|
Spectral power distribution in the range 250 nm to 800 nm, at full-load
|
|
|
Width
|
35 mm
|
|
Depth
|
35 mm
|
|
Claim of equivalent power (3)
|
N/A
|
If yes, equivalent power (W)
|
|
|
|
|
Chromaticity coordinates (x and y)
|
X:0.4400
Y:0.4030
|
|
Parameters for directional light sources:
|
|
Peak luminous intensity (cd)
|
N/A
|
Beam angle in degrees, or the range of beam angles that can be set
|
300°
|
|
Parameters for LED and OLED light sources:
|
|
R9 colour rendering index value
|
18
|
Survival factor
|
≥90%
|
|
the lumen maintenance factor
|
|
|
|
|
Parameters for LED and OLED mains light sources:
|
|
displacement factor (cos φ1)
|
N/A
|
Colour consistency in McAdam ellipses
|
|
|
Claims that an LED light source replaces a fluorescent light source without integrated ballast of a particular wattage.
|
N/A
|
If yes then replacement claim (W)
|
N/A
|
|
Flicker metric (Pst LM)
|
|
Stroboscopic effect metric (SVM)
|
|
