Supplier’s name or trade mark: CHANGZHOU
TOPKING INTERNATIONAL TRADE CO., LTD
|
|
Supplier’s address (1) :room 409.no.1 fuchen building.no.8 taihu east
road,changzhou.jiangsu.china
|
|
Model identifier: RS-BJ004
|
|
Type of light source: LED
|
|
Lighting technology used:
|
LED
|
Non-directional or directional:
|
NDLS
|
|
Light source cap-type(or other electric interface)
|
E14
|
|
|
|
Mains or non-mains:
|
MLS
|
Connected light source (CLS):
|
NO
|
|
Colour-tuneable light source:
|
NO
|
Envelope:
|
NO
|
|
High luminance light source:
|
NO
|
|
|
|
Anti-glare shield:
|
NO
|
Dimmable:
|
NO
|
|
Product parameters
|
|
Parameter
|
4W
|
Parameter
|
6500K
|
|
General product parameters:
|
|
Energy consumption
in on-mode (kWh/1 000 h)
|
4
|
Energy efficiency class
|
E
|
|
Useful luminous flux (Φuse), indicating if it
refers to the flux in a sphere (360°), in a wide cone (120°) or in a narrow
cone (90°)
|
470Lm
|
Correlated colour temperature, rounded to the nearest 100 K,
or the range of correlated colour temperatures, rounded to the nearest 100
K, that can be set
|
6500k
|
|
On-mode power (Pon), expressed in W
|
4W
|
Standby power (Psb), expressed in W
and rounded to the second decimal
|
NO
|
|
Networked standby power (Pnet) for CLS,
expressed in W and rounded to the second decimal
|
N/A
|
Colour rendering index, rounded to the nearest integer, or the
range of CRI-values that can be set
|
80
|
|
Outer dimensions without separate control gear, lighting
control parts and non-lighting control parts, if any (millimetre)
|
Height
|
100mm
|
Spectral power distribution in the range 250 nm to 800 nm, at
full-load
|
|
|
Width
|
37mm
|
|
Depth
|
37 mm
|
|
Claim of equivalent power (3)
|
N/A
|
If yes, equivalent power (W)
|
|
|
|
|
Chromaticity coordinates (x and y)
|
X:0.3085
Y:0.3333
|
|
Parameters for directional light
sources:
|
|
Peak luminous intensity (cd)
|
N/A
|
Beam angle in degrees, or the range of beam angles that can be
set
|
200°
|
|
Parameters for LED and OLED light
sources:
|
|
R9 colour rendering index value
|
7
|
Survival factor
|
≥90%
|
|
the lumen maintenance factor
|
|
|
|
|
Parameters for LED and OLED mains
light sources:
|
|
displacement factor (cos φ1)
|
N/A
|
Colour consistency in McAdam ellipses
|
|
|
Claims that an LED light source replaces a fluorescent light
source without integrated ballast of a particular wattage.
|
N/A
|
If yes then replacement claim (W)
|
N/A
|
|
Flicker metric (Pst LM)
|
|
Stroboscopic effect metric (SVM)
|
|
